DELTA 1-24 LSCplus

DELTA 1-24 LSCplus
Overview
Overview
PDF

Freeze dryer DELTA 1-24 LSCplus

Total ice capacity 24 kg,

Ice condenser temperature –55°C.

High-performance, mobile freeze dryer for advanced processes; low ice condenser temperature allow drying of samples containing organic solvents (e.g. alcohols); with new intuitive understandable unit control LSCplus "Lyo Screen Control plus".

Performance characteristics

  • Colour touchscreen and intuitive operation
  • Clear structured display of relevant process data
  • Storage of up to 30 freeze drying programs in tables (option)
  • Wireless heated shelves
  • WINDOWS based process control and documentation software is available
  • ECO: natural refrigerant, K6 compliant

Manufacturer

For further information:

www.martinchrist.de

Further information


Possible configurations

Process A: freezing and drying in ice condenser chamber:

  • 10 shelves Ø 200 mm
  • 4 shelves with sealing device Ø 250 mm
  • Temperature range approx. -40°C ... +50°C

Process B: freezing separately, drying outside of ice condenser chamber:

  • 12 or 24 round-bottom-flasks
  • 5 or 10 heated shelves Ø 200 mm
  • 8 heated shelves Ø 375 mm
  • 2 or 4 heated shelves Ø 250 mm with sealing device
